Do I need to remove the bumper before removing the Lexus LC500 fender?

Yes. The front bumper and headlight must be removed before the fender can be accessed and detached.

What size socket is used to remove the Lexus LC500 fender bolts?

A 10mm socket is used for the bolts shown in the video.

Are there bolts behind the side skirt on the Lexus LC500?

Yes. The side skirt must be gently pulled back to access and remove bolts located behind it.

How to Remove a 2018-2025 Lexus LC500 Front Fender

Removing the front fender on a Lexus LC500 requires accessing bolts along the top, side, and behind the side skirt. This guide follows the exact process shown in the video and walks through each fastener location in order.

Before starting, the front bumper and headlight must already be removed, as the fender cannot be accessed properly without removing those components first.

Tools Needed

Panel removal tool or flathead screwdriver
10mm socket
Extension
Ratchet (power or handheld)
Phillips screwdriver
Flat tool

Step-by-Step Guide

Step 1: Remove Upper Plastic Cover

Remove the upper plastic cover by prying out the plastic push pins. Once all push pins are removed, lift the cover off.

Removing upper plastic cover from Lexus LC500 engine bay

Step 2: Remove Top Fender Bolts

Remove the four 10mm bolts located along the top of the fender using a 10mm socket with an extension and ratchet.

Removing top 10mm bolts from Lexus LC500 front fender

Step 3: Remove Side Fender Bolts

Remove the 10mm bolts located along the side of the fender.

Removing side 10mm bolts from Lexus LC500 front fender

Step 4: Remove Side Push Pins

Remove the plastic push pins along the side and underneath the fender area using a flathead screwdriver.

Removing plastic push pins from Lexus LC500 fender liner

Step 5: Remove Lower Fender Clip and Bolt

Remove the lower clip and the additional bolt located near the bottom of the fender liner area.

Removing lower clip and bolt from Lexus LC500 fender liner area

Step 6: Remove Door Area Plastic Covers

Open the door and pry off the plastic covers located inside the door area using a flat tool.

Removing plastic cover inside Lexus LC500 door jamb area

Step 7: Remove Door Area Screws

Remove the screws located behind the plastic covers inside the door area using a Phillips screwdriver.

Removing screws behind plastic cover in Lexus LC500 door area

Step 8: Pull Back Side Skirt and Remove Hidden Bolts

Gently pull back the side skirt by releasing the clips to create access. Press down slightly as needed and remove the bolts located behind the side skirt using a handheld ratchet.

Pulling back Lexus LC500 side skirt to remove hidden fender bolts

Step 9: Remove Fender-Side Screws

Pull down the plastic cover near the door area and remove the remaining screws on the fender side.

Removing remaining screws on Lexus LC500 fender side

Step 10: Remove the Fender

After all bolts and fasteners are removed, pull the fender outward to detach it from the vehicle.

Lexus LC500 front fender being pulled outward for removal

Need a Replacement Fender?

If you are replacing a damaged fender, pre-painted Lexus LC500 front fenders are available and ready to install.

Shop Lexus LC500 Painted Fender
